E2E Visual Comparison Report

Generated: 2026-11-22T02:49:13.169Z

MapLibre is the reference. SVG vs ML and PNG vs ML grade each renderer against it; drift is the two renderers against each other, which catches one backend diverging even while both stay close to MapLibre.

Region MapLibre (reference) SVG renderer PNG renderer Diff: SVG vs ML Diff: PNG vs ML Drift: SVG vs PNG
berlin-vector
lon: 13.357
lat: 52.515
zoom: 14.2
style: vector
SVG: 1794 KB
PNG: 1382 KB
SVG vs ML: 1.24% (was 1.26%)
PNG vs ML: 0.90% (was 0.88%)
drift: 0.43% (was 0.43%)
paris-vector
lon: 2.295
lat: 48.858
zoom: 14.9
style: vector
SVG: 1416 KB
PNG: 1543 KB
SVG vs ML: 0.77% (was 0.77%)
PNG vs ML: 0.57% (was 0.57%)
drift: 0.22% (was 0.22%)
warsaw-vector
lon: 21.013
lat: 52.249
zoom: 14.9
style: vector
SVG: 1625 KB
PNG: 1618 KB
SVG vs ML: 1.41% (was 1.39%)
PNG vs ML: 1.04% (was 1.04%)
drift: 0.38% (was 0.40%)
tokyo-vector
lon: 139.692
lat: 35.69
zoom: 10
style: vector
SVG: 1257 KB
PNG: 1472 KB
SVG vs ML: 1.19% (was 1.20%)
PNG vs ML: 0.66% (was 0.70%)
drift: 0.82% (was 0.82%)
roma-vector
lon: 12.489
lat: 41.89
zoom: 14.9
style: vector
SVG: 3144 KB
PNG: 1759 KB
SVG vs ML: 1.23% (was 1.25%)
PNG vs ML: 0.86% (was 0.90%)
drift: 0.34% (was 0.37%)
sao-paulo-vector
lon: -46.635
lat: -23.548
zoom: 14
style: vector
SVG: 678 KB
PNG: 1323 KB
SVG vs ML: 0.61% (was 0.64%)
PNG vs ML: 0.25% (was 0.27%)
drift: 0.55% (was 0.55%)
berlin-labels-vector
lon: 13.357
lat: 52.515
zoom: 14.2
style: vector + labels
SVG: 2004 KB
PNG: 1505 KB
SVG vs ML: 5.30% (was 5.31%)
PNG vs ML: 5.01% (was 5.02%)
drift: 0.69% (was 0.69%)
berlin-pmtiles-vector
lon: 13.357
lat: 52.515
zoom: 14.2
style: pmtiles
SVG: 1794 KB
PNG: 1382 KB
SVG vs ML: 1.24% (was 1.26%)
PNG vs ML: 0.90% (was 0.87%)
drift: 0.43% (was 0.43%)
berlin-mlt-vector
lon: 13.357
lat: 52.515
zoom: 14.2
style: mlt
SVG: 1794 KB
PNG: 1382 KB
SVG vs ML: 1.24% (was 1.26%)
PNG vs ML: 0.90% (was 0.87%)
drift: 0.43% (was 0.43%)
berlin-outlines-vector
lon: 13.399
lat: 52.519
zoom: 15.5
style: vector
SVG: 814 KB
PNG: 1388 KB
SVG vs ML: 1.07% (was 1.07%)
PNG vs ML: 0.84% (was 0.84%)
drift: 0.20% (was 0.20%)
berlin-rotated-vector
lon: 13.357
lat: 52.515
zoom: 14.2
bearing: 30
style: vector
SVG: 2414 KB
PNG: 1496 KB
SVG vs ML: 1.14% (was 1.14%)
PNG vs ML: 0.77% (was 0.79%)
drift: 0.41% (was 0.42%)
berlin-labels-rotated-vector
lon: 13.357
lat: 52.515
zoom: 14.2
bearing: -60
style: vector + labels
SVG: 2676 KB
PNG: 1711 KB
SVG vs ML: 5.09% (was 5.05%)
PNG vs ML: 4.72% (was 4.72%)
drift: 0.73% (was 0.73%)
berlin-rotated-satellite
lon: 13.376
lat: 52.518
zoom: 15
bearing: -45
style: satellite
SVG: 684 KB
PNG: 3031 KB
SVG vs ML: 0.22% (was 0.22%)
PNG vs ML: 0.22% (was 0.22%)
drift: 0.00% (was 0.00%)
parity-rotated-features
lon: 0
lat: 0
zoom: 12
bearing: 30
style: features
SVG: 309 KB
PNG: 265 KB
SVG vs ML: 0.03% (was 0.03%)
PNG vs ML: 0.03% (was 0.03%)
drift: 0.00% (was 0.00%)
cellSVGPNGdrift
fill-sort-key0.07%0.07%0.00%
line-sort-key0.00%0.00%0.00%
circle-sort-key0.00%0.00%0.00%
circle opacities, circle-blur0.00%0.01%0.00%
line-gap-width0.02%0.02%0.00%
global-state0.00%0.00%0.00%
fill-pattern0.01%0.01%0.00%
translucent pattern, outline0.14%0.12%0.03%
data-driven pattern, missing image0.00%0.00%0.00%
parity-rotated-sources
lon: 0
lat: 0
zoom: 12
bearing: 30
style: sources
SVG: 281 KB
PNG: 282 KB
SVG vs ML: 0.06% (was 0.06%)
PNG vs ML: 0.06% (was 0.06%)
drift: 0.00% (was 0.00%)
cellSVGPNGdrift
image0.00%0.00%0.00%
skewed image0.00%0.00%0.00%
image in perspective0.43%0.46%0.00%
translucent image0.16%0.15%0.01%
strongly foreshortened image0.16%0.16%0.02%
mirrored image0.00%0.00%0.00%
GeoJSON filter0.00%0.00%0.00%
GeoJSON promoteId0.00%0.00%0.00%
GeoJSON generateId0.00%0.00%0.00%
parity-rotated-patterns
lon: 0
lat: 0
zoom: 12
bearing: 30
style: patterns
SVG: 7 KB
PNG: 278 KB
SVG vs ML: 0.56% (was 0.56%)
PNG vs ML: 0.54% (was 0.54%)
drift: 0.09% (was 0.09%)
cellSVGPNGdrift
line-pattern0.22%0.19%0.09%
turns (miter joins)0.44%0.42%0.08%
round joins and caps0.94%0.74%0.10%
on a polygon0.88%0.89%0.21%
zoom-dependent width0.15%0.17%0.01%
translucent0.19%0.19%0.03%
data-driven, missing one0.83%0.67%0.21%
going west, then south0.42%0.41%0.11%
fill-pattern1.27%1.31%0.00%
parity-rotated-dashes
lon: 0
lat: 0
zoom: 12
bearing: 30
style: dashes
SVG: 2 KB
PNG: 82 KB
SVG vs ML: 0.04% (was 0.04%)
PNG vs ML: 0.04% (was 0.04%)
drift: 0.02% (was 0.02%)
cellSVGPNGdrift
thin, short dashes0.10%0.12%0.14%
butt caps, turns0.04%0.03%0.00%
round caps and joins0.01%0.01%0.00%
on a polygon0.02%0.02%0.00%
zoom-dependent width0.00%0.00%0.00%
translucent0.00%0.00%0.00%
odd number of values0.00%0.00%0.00%
going west, then south0.00%0.01%0.00%
square caps0.17%0.16%0.00%
berlin-padded-vector
lon: 13.357
lat: 52.515
zoom: 14.2
style: vector
SVG: 2955 KB
PNG: 1519 KB
SVG vs ML: 1.37% (was 1.38%)
PNG vs ML: 0.92% (was 0.93%)
drift: 0.49% (was 0.50%)
berlin-padded-satellite
lon: 13.376
lat: 52.518
zoom: 15
bearing: 30
style: satellite
SVG: 683 KB
PNG: 3141 KB
SVG vs ML: 0.32% (was 0.32%)
PNG vs ML: 0.26% (was 0.26%)
drift: 0.00% (was 0.00%)
europe-padded-vector-globe
lon: 12
lat: 50
zoom: 3.5
style: vector, globe
SVG: 879 KB
PNG: 271 KB
SVG vs ML: 0.20% (was 0.20%)
PNG vs ML: 0.17% (was 0.17%)
drift: 0.04% (was 0.04%)
europe-rotated-vector-globe
lon: 12
lat: 50
zoom: 3.5
bearing: 20
style: vector, globe
SVG: 977 KB
PNG: 317 KB
SVG vs ML: 0.22% (was 0.22%)
PNG vs ML: 0.20% (was 0.20%)
drift: 0.05% (was 0.05%)
berlin-satellite
lon: 13.376
lat: 52.518
zoom: 15
style: satellite
SVG: 428 KB
PNG: 2664 KB
SVG vs ML: 0.40% (was 0.40%)
PNG vs ML: 0.55% (was 0.55%)
drift: 0.02% (was 0.02%)
berlin-geojson
lon: 13.388
lat: 52.514
zoom: 14
style: geojson
SVG: 5 KB
PNG: 41 KB
SVG vs ML: 1.48% (was 1.48%)
PNG vs ML: 1.68% (was 1.68%)
drift: 0.79% (was 0.82%)
parity-features
lon: 0
lat: 0
zoom: 12
style: features
SVG: 308 KB
PNG: 84 KB
SVG vs ML: 0.07% (was 0.07%)
PNG vs ML: 0.05% (was 0.05%)
drift: 0.00% (was 0.00%)
cellSVGPNGdrift
fill-sort-key0.21%0.21%0.00%
line-sort-key0.00%0.00%0.00%
circle-sort-key0.00%0.00%0.00%
circle opacities, circle-blur0.00%0.02%0.00%
line-gap-width0.02%0.02%0.00%
global-state0.00%0.00%0.00%
fill-pattern0.00%0.00%0.00%
translucent pattern, outline0.39%0.20%0.00%
data-driven pattern, missing image0.01%0.00%0.01%
parity-symbols
lon: 0
lat: 0
zoom: 12
style: symbols + labels
SVG: 32 KB
PNG: 75 KB
SVG vs ML: 0.11% (was 0.11%)
PNG vs ML: 0.11% (was 0.11%)
drift: 0.01% (was 0.01%)
cellSVGPNGdrift
fit both, padding0.01%0.02%0.01%
fit width0.07%0.09%0.00%
fit height, two lines0.04%0.05%0.01%
plain image, fit both0.41%0.42%0.08%
fit both, icon-size0.25%0.26%0.00%
plain image, turned0.13%0.13%0.00%
fit both, on a line0.01%0.01%0.00%
turned icon, offset0.03%0.03%0.00%
fit both, anchor + offset0.03%0.03%0.00%
parity-anchors
lon: 0
lat: 0
zoom: 12
style: anchors + labels
SVG: 17 KB
PNG: 57 KB
SVG vs ML: 0.42% (was 0.41%)
PNG vs ML: 0.40% (was 0.40%)
drift: 0.01% (was 0.01%)
cellSVGPNGdrift
first place free0.06%0.06%0.00%
first place blocked0.08%0.08%0.00%
all blocked: hidden1.40%1.36%0.01%
all blocked, may overlap1.74%1.71%0.08%
radial offset only0.09%0.08%0.00%
variable-anchor-offset0.08%0.07%0.00%
fitted icon moves along0.09%0.09%0.00%
two lines, justified0.14%0.13%0.00%
icon stays, not fitted0.09%0.07%0.02%
parity-scripts
lon: 0
lat: 0
zoom: 12
style: scripts + labels
SVG: 43 KB
PNG: 105 KB
SVG vs ML: 0.10% (was 0.10%)
PNG vs ML: 0.10% (was 0.10%)
drift: 0.00% (was 0.00%)
cellSVGPNGdrift
Hebrew along a line0.07%0.06%0.00%
Hebrew, Latin, brackets0.11%0.10%0.01%
Arabic along a line0.09%0.08%0.01%
Arabic0.11%0.10%0.00%
Arabic over Latin0.15%0.15%0.00%
Persian0.08%0.08%0.00%
Arabic with digits along a line0.12%0.11%0.01%
Arabic on several lines0.12%0.12%0.00%
Arabic with letter spacing0.09%0.09%0.00%
parity-combining
lon: 0
lat: 0
zoom: 12
style: combining + labels
SVG: 7 KB
PNG: 91 KB
SVG vs ML: 0.57% (was 0.57%)
PNG vs ML: 0.39% (was 0.39%)
drift: 0.10% (was 0.10%)
cellSVGPNGdrift
Devanagari along a line1.38%1.31%0.09%
Devanagari0.67%0.45%0.04%
Thai along a line0.27%0.26%0.02%
Bengali0.20%0.04%0.07%
Thai1.44%0.50%0.51%
Tamil0.28%0.14%0.05%
Hebrew with points along a line0.56%0.58%0.08%
Khmer0.16%0.15%0.07%
Myanmar0.21%0.04%0.04%
parity-cjk
lon: 0
lat: 0
zoom: 12
style: cjk + labels
SVG: 6 KB
PNG: 93 KB
SVG vs ML: 0.59% (was 0.59%)
PNG vs ML: 0.83% (was 0.89%)
drift: 0.68% ▼ (was 0.79%)
cellSVGPNGdrift
Chinese along a line0.28%0.31%0.37%
Chinese0.52%0.38% ▼0.46% ▼
Chinese along a steep line0.21%0.32%0.35%
Japanese0.22%0.62%0.86%
Korean0.16%1.09%1.05%
Chinese, two lines0.83%1.15% ▼1.26% ▼
vertical writing mode0.94%1.29% ▼1.05% ▼
Japanese and Latin1.21%1.28%0.36%
Japanese with a number, steep line0.94%1.07%0.39%
parity-halos
lon: 0
lat: 0
zoom: 12
style: halos + labels
SVG: 9 KB
PNG: 48 KB
SVG vs ML: 0.25% (was 0.25%)
PNG vs ML: 0.22% (was 0.22%)
drift: 0.02% (was 0.02%)
cellSVGPNGdrift
12 px, halo 10.18%0.16%0.07%
12 px, halo 3 (capped)0.15%0.13%0.00%
24 px, halo 10.12%0.11%0.00%
24 px, halo 30.03%0.02%0.00%
24 px, halo 6 (capped)0.58%0.55%0.00%
40 px, halo 20.02%0.02%0.00%
40 px, halo 8 (capped)0.91%0.86%0.00%
translucent halo0.06%0.05%0.00%
Thai, 24 px, halo 30.23%0.04%0.07%
parity-overlap
lon: 0
lat: 0
zoom: 12
style: overlap + labels
SVG: 21 KB
PNG: 68 KB
SVG vs ML: 0.22% (was 0.22%)
PNG vs ML: 0.22% (was 0.22%)
drift: 0.01% (was 0.01%)
cellSVGPNGdrift
never beats allow-overlap0.16%0.15%0.00%
always0.36%0.34%0.00%
cooperative among selves0.14%0.14%0.00%
cooperative, never above0.22%0.21%0.00%
cooperative, always above0.10%0.10%0.00%
variable anchors0.13%0.12%0.00%
icons, cooperative0.54%0.55%0.09%
parity-sources
lon: 0
lat: 0
zoom: 12
style: sources
SVG: 338 KB
PNG: 106 KB
SVG vs ML: 0.11% (was 0.11%)
PNG vs ML: 0.18% (was 0.18%)
drift: 0.19% (was 0.19%)
cellSVGPNGdrift
image0.12%0.49%0.93%
skewed image0.00%0.00%0.00%
image in perspective0.31%0.35%0.00%
translucent image0.27%0.27%0.43%
strongly foreshortened image0.34%0.29%0.06%
mirrored image0.00%0.26%0.26%
GeoJSON filter0.00%0.00%0.00%
GeoJSON promoteId0.00%0.00%0.00%
GeoJSON generateId0.00%0.00%0.00%
parity-patterns
lon: 0
lat: 0
zoom: 12
style: patterns
SVG: 7 KB
PNG: 86 KB
SVG vs ML: 0.57% (was 0.57%)
PNG vs ML: 0.46% (was 0.48%)
drift: 0.09% (was 0.09%)
cellSVGPNGdrift
line-pattern0.32%0.23%0.13%
turns (miter joins)0.48%0.50%0.11%
round joins and caps1.23%0.96%0.28%
on a polygon1.13%1.14%0.04%
zoom-dependent width0.19%0.21%0.01%
translucent0.28%0.24%0.03%
data-driven, missing one0.59%0.32%0.12%
going west, then south0.48%0.54%0.05%
fill-pattern0.38%0.04%0.00%
parity-patterns-z11.5
lon: 0
lat: 0
zoom: 11.5
style: patterns
SVG: 7 KB
PNG: 67 KB
SVG vs ML: 1.01% (was 1.01%)
PNG vs ML: 0.68% (was 0.68%)
drift: 0.41% (was 0.41%)
cellSVGPNGdrift
line-pattern0.25%0.17%0.05%
turns (miter joins)0.87%0.81%0.12%
round joins and caps0.65%0.54%0.09%
on a polygon1.27%1.20%0.19%
zoom-dependent width0.38%0.14%0.31%
translucent0.36%0.28%0.02%
data-driven, missing one0.35%0.22%0.05%
going west, then south0.59%0.51%0.10%
fill-pattern3.57%1.90%2.22%
parity-images
lon: 0
lat: 0
zoom: 12
style: images + labels
SVG: 71 KB
PNG: 29 KB
SVG vs ML: 0.27% (was 0.27%)
PNG vs ML: 0.16% (was 0.16%)
drift: 0.17% (was 0.17%)
cellSVGPNGdrift
SDF icon, colored0.00%0.00%0.02%
SDF icon, halo1.03%0.03%1.28%
SDF icon, pixelRatio 20.00%0.00%0.01%
RGBA icon0.00%0.09%0.07%
fill-pattern0.26%0.26%0.00%
line-pattern0.42%0.37%0.02%
parity-dashes
lon: 0
lat: 0
zoom: 12
style: dashes
SVG: 2 KB
PNG: 56 KB
SVG vs ML: 0.06% (was 0.06%)
PNG vs ML: 0.05% (was 0.05%)
drift: 0.01% (was 0.01%)
cellSVGPNGdrift
thin, short dashes0.20%0.19%0.12%
butt caps, turns0.04%0.04%0.00%
round caps and joins0.03%0.03%0.00%
on a polygon0.03%0.03%0.00%
zoom-dependent width0.00%0.00%0.00%
translucent0.00%0.00%0.00%
odd number of values0.00%0.00%0.00%
going west, then south0.01%0.01%0.00%
square caps0.22%0.18%0.00%
parity-dashes-z11.5
lon: 0
lat: 0
zoom: 11.5
style: dashes
SVG: 2 KB
PNG: 42 KB
SVG vs ML: 0.06% (was 0.06%)
PNG vs ML: 0.06% (was 0.06%)
drift: 0.00% (was 0.00%)
cellSVGPNGdrift
thin, short dashes0.11%0.12%0.00%
butt caps, turns0.05%0.05%0.00%
round caps and joins0.05%0.05%0.00%
on a polygon0.07%0.07%0.00%
zoom-dependent width0.05%0.05%0.00%
translucent0.02%0.02%0.00%
odd number of values0.01%0.01%0.00%
going west, then south0.02%0.02%0.00%
square caps0.09%0.09%0.00%
parity-tile-seams
lon: 0.01
lat: 0.007
zoom: 12.5
style: seams
SVG: 1 KB
PNG: 10 KB
SVG vs ML: 0.00% (was 0.00%)
PNG vs ML: 0.00% (was 0.00%)
drift: 0.00% (was 0.00%)
world-vector-globe
lon: 10
lat: 20
zoom: 2
style: vector, globe
SVG: 693 KB
PNG: 243 KB
SVG vs ML: 0.35% (was 0.35%)
PNG vs ML: 0.52% (was 0.52%)
drift: 0.19% (was 0.19%)
europe-vector-globe
lon: 12
lat: 50
zoom: 3.5
style: vector, globe
SVG: 975 KB
PNG: 311 KB
SVG vs ML: 0.22% (was 0.22%)
PNG vs ML: 0.19% (was 0.20%)
drift: 0.04% (was 0.04%)
scandinavia-vector-globe
lon: 20
lat: 68
zoom: 5
style: vector, globe
SVG: 897 KB
PNG: 419 KB
SVG vs ML: 0.37% (was 0.37%)
PNG vs ML: 0.21% (was 0.21%)
drift: 0.05% (was 0.04%)
japan-vector-globe
lon: 138.5
lat: 36
zoom: 7
style: vector, globe
SVG: 846 KB
PNG: 1088 KB
SVG vs ML: 1.25% (was 1.30%)
PNG vs ML: 0.59% (was 0.67%)
drift: 0.95% (was 0.93%)
tokyo-z11.5-vector-globe
lon: 139.692
lat: 35.69
zoom: 11.5
style: vector, globe
SVG: 1900 KB
PNG: 1674 KB
SVG vs ML: 1.84% (was 1.83%)
PNG vs ML: 1.30% (was 1.23%)
drift: 1.10% (was 1.01%)
world-satellite-globe
lon: 10
lat: 20
zoom: 2
style: satellite, globe
SVG: 870 KB
PNG: 1138 KB
SVG vs ML: 0.59% (was 0.59%)
PNG vs ML: 0.67% (was 0.70%)
drift: 0.04% (was 0.06%)
europe-satellite-globe
lon: 12
lat: 50
zoom: 3.5
style: satellite, globe
SVG: 375 KB
PNG: 1749 KB
SVG vs ML: 0.70% (was 0.70%)
PNG vs ML: 0.70% (was 0.70%)
drift: 0.00% (was 0.00%)
